Input Voltage MIN (V) : 20

Input Voltage MAX (V) : 30

Output Max Current (A) : 12

Output Voltage (V) : 13.5

Output Connector : Spade (faston)

Output Wattage (W) : 165

Isolation : Non-isolated, common ground

Output max Current <60sec (A) : 16

Protections : Output short protected

Cooling (passive if not specified) :

Output Ripple(mV or %) : 5mV

Style : Enclosed module

Safety : CE

Notes :

Environment : -10C to +55C operating, -40C to +90C storage

Humidity max (%) : 90

Efficiency (%) : 49

HiPot/ESD :

Input Frequency(Hz) : DC

Input Connector : Spade (faston)

MTBF :

Weight (g) : 670.00
