Input Voltage MIN (V) : 18

Input Voltage MAX (V) : 28

Output Max Current (A) : 20

Output Voltage (V) : 12.5-15.5

Output Connector : Banana plug +screw terminal

Output Wattage (W) : 270

Isolation : Non-isolated, common ground

Output max Current <60sec (A) :

Protections : Over Voltage, Over Current, Reverse Polarity, Over Load

Cooling (passive if not specified) :

Output Ripple(mV or %) : 50mV

Style : Enclosed module

Safety :

Notes :

Environment : 0C to +40C operating, -40C to +75C storage

Humidity max (%) : 95

Efficiency (%) : 85

HiPot/ESD :

Input Frequency(Hz) : DC

Input Connector : Screw terminal

MTBF :

Weight (g) : 1500.00
