Input Voltage MIN (V) : 10.5

Input Voltage MAX (V) : 18

Output Max Current (A) : 15.5

Output Voltage (V) : 24-27.5

Output Connector : Screw terminal

Output Wattage (W) : 360

Isolation : Non-isolated, common ground

Output max Current <60sec (A) : 20

Protections : Output short protected

Cooling (passive if not specified) :

Output Ripple(mV or %) : 10mV

Style : Enclosed module

Safety : Over Voltage, Over Current, Short Circuit , Reverse Polarity , Over Load

Notes :

Environment : -25C to +40C operating, -40C to +90C storage

Humidity max (%) : 90

Efficiency (%) : 90

HiPot/ESD :

Input Frequency(Hz) : DC

Input Connector : Screw terminal

MTBF : Heavy Duty Industrial

Weight (g) : 1800.00
